FK COM/COMH Series Spherical Bearings COM10T
SPECIAL ORDER ITEM
This is a special order item. When you complete your order, we will order it from the supplier.
FREIGHT INFORMATION
Pricing does not include additional freight charge.
Request a quote below.
Manufacturer's Part Number: COM10T
Part Type: Rod End Receiver Bearings
Product Line: FK COM/COMH Series Spherical Bearings
Automotive Fittings Part Number: FKB-COM10T
Receiver Race Diameter: 1.1875 in.
Race Width: 0.500 in.
Inner Ball Width: 0.625 in.
Inner Ball Diameter: 0.6250 in.
Rod End Ball Diameter: 0.968 in.
Chamfer Reference: 0.032 in.
Rod End Misalign Angle: 8.5 degrees
ULT. Static Radial Load (lbs.): 21,280 lbs.
Rod End Bearing Material: Steel
Quantity: Sold individually.
Notes: Features PTFE liner.
Description:
FK COM/COMH spherical bearings are part of their commercial series. Precision-made from quality materials, these rod end bearings are tough and reliable to handle your stressed applications. Order the size, load rating, and other options needed for replacement or upgrade.
COM/COMH Series offers:
* 52100 heat-treated steel with hard chrome plate ball
* Low-carbon steel and oil coated race
