JE Pistons APBA 305 Pistons 174004S
SPECIAL ORDER ITEM
This is a special order item. When you complete your order, we will order it from the supplier.
FREIGHT INFORMATION
Pricing does not include additional freight charge.
Request a quote below.
Manufacturer's Part Number: 174004S
Part Type: Pistons
Product Line: JE Pistons APBA 305 Pistons
Automotive Fittings Part Number: JEP-174004-1
UPC: 193564186300
Piston Rings Included: No
Bore (in.): 3.766 in.
Bore (mm): 95.656mm
Stroke: 3.480 in.
Engine Stroke Type: Stock
Rod Length: 5.700 in.
Piston Style: Flat top, with four valve reliefs
Piston Material: Forged aluminum
Compression Height (in.): 1.560 in.
Piston Head Volume (cc): +5.00cc
Wrist Pin Style: Press-fit or floating
Wrist Pin Retainers Included: Yes
Wrist Pin Included: Yes
Pin Diameter (in.): 0.927 in.
Piston Ring Thickness: 5/64 in. x 5/64 in. x 3/16 in.
File Fit: No
Gapless: No
Remanufactured: No
Quantity: Sold individually.
Description:
JE Pistons APBA 305 pistons are approved replacement pistons for the 305 class. Available in a 4-valve relief flat top as well as a dish, they accept original equipment manufacturer 5/64, 5/64, 3/16 rings and are manufactured for a press pin. All APBA pistons have the APBA logo laser-etched on the top of the piston. They include a 134g wrist pin.
