MSD Pro Power Coils 8201
SPECIAL ORDER ITEM
This is a special order item. When you complete your order, we will order it from the supplier.
FREIGHT INFORMATION
Pricing does not include additional freight charge.
Request a quote below.
Manufacturer's Part Number: 8201
Part Type: Ignition Coils
Product Line: MSD Pro Power Coils
Automotive Fittings Part Number: MSD-8201
UPC: 085132082018
Coil Style: Remote mount
Primary Resistance: 0.030 ohms
Coil Internal Construction: Ciba arathane
Coil Wire Attachment: Male/HEI
Coil Color: Red
Maximum Voltage: 43,000 V
Turns Ratio: 100:1
Secondary Resistance: 2.40K ohms
Inductance: 1.00 mH
Peak Current: 800 mA
Spark Duration: 180 uS
Mounting Bracket Included: No
Coil Wire Included: No
Ballast Resistor Included: No
Coil Shape: Square
Height (in.): 2.500 in.
Length (in.): 5.250 in.
Width (in.): 9.375 in.
Quantity: Sold individually.
Notes: For MSD 7AL, 8 and 10 Ignitions only. Not for use with MSD 6 or Digital-7-Series Ignitions.
Description:
When tested against a competitor's coil, the MSD Pro Power coils produced 33 percent more current at the plug. They have an oil-filled insulated polyester case, an extra-tall high-tension spark plug tower to stop voltage leaks, and rubber shock mounts. They're designed for drag race use only, with MSD 7 and 8 Series ignitions.
What does "Will be special ordered for you" mean?
This means that we do not have the product in our warehouse. We only order “Special Order” products from the supplier when you order them from us. Generally, we do not intend to keep an inventory of these items. Therefore, returns are not possible.
“Special Order” products could be shipped directly from the supplier or they could be shipped to us first. Then, we would ship it to you. The available shipping options will be provided during the checkout process.
