Trick Flow® GenX® 185 Cylinder Heads for GM LT1 TFS-3041B008-M54
SPECIAL ORDER ITEM
This is a special order item. When you complete your order, we will order it from the supplier.
FREIGHT INFORMATION
Pricing does not include additional freight charge.
Request a quote below.
Manufacturer's Part Number: TFS-3041B008-M54
Part Type: Cylinder Heads
Product Line: Trick Flow® GenX® 185 Cylinder Heads for GM LT1
Automotive Fittings Part Number: TFS-3041B008-M54
UPC: 842645106569
Combustion Chamber Volume (cc): 54
Intake Runner Volume (cc): 185cc
Exhaust Runner Volume (cc): 67cc
Cylinder Head Style: Bare
Cylinder Head Material: Cast aluminum
Intake Port Shape: Rectangular
Intake Valve Diameter (in.): 2.020 in.
CNC-Machined Combustion Chamber: Yes
CNC-Machined Intake Runner: No
CNC-Machined Exhaust Runner: No
Combustion Chamber Style: Heart
Intake Port Location: Standard
Exhaust Port Shape: D-port
Exhaust Port Location: Standard
Spark Plug Style: Angle
Intake Valves Included: No
Exhaust Valves Included: No
Exhaust Valve Diameter (in.): 1.600 in.
Valve Springs Included: No
Damper Spring Included: No
Retainers Included: No
Locks Included: No
Valve Stem Seals Included: No
Rocker Arm Studs Included: No
Rocker Arms Included: No
Rocker Arm Nuts Included: No
Guideplates Included: No
Valve Cover Mounting Style: Centerbolt
Accessory Bolt Holes Drilled: Yes
Intake Valve Angle: 21
Exhaust Valve Angle: 21
Valve Guides Included: Yes
Valve Guide Material: Bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Ductile iron
Cylinder Head Color: Natural
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: No
Remanufactured: No
Quantity: Sold individually.
Notes: Requires a minimum bore diameter of 4.000 in.
Description:
Trick Flow® GenX® 185 cylinder heads give you performance that closely matches CNC-ported cylinder heads—for about the same price as ordinary cast heads! Designed for naturally aspirated GM LT1 engines, the GenX 185 heads retain the factory compression ratio and have standard resolution CNC profiled combustion chambers to amplify performance. The valve angles were reduced to 21° from stock to increase piston-to-valve clearance and unshroud the chambers for better airflow. Power-building Fast As Cast® runners duplicate the profiles of fully CNC-ported heads, resulting in high airflow rates without costly CNC-porting. These heads accept all stock sensors and fittings.
Trick Flow GenX 185 cylinder heads are available fully assembled or as bare castings. Sold individually.
