Wilwood Ultralite HP 32 Vane Rotor and Hats 160-11520
SPECIAL ORDER ITEM
This is a special order item. When you complete your order, we will order it from the supplier.
FREIGHT INFORMATION
Pricing does not include additional freight charge.
Request a quote below.
Manufacturer's Part Number: 160-11520
Part Type: Brake Rotors
Product Line: Wilwood Ultralite HP 32 Vane Rotor and Hats
Automotive Fittings Part Number: WIL-160-11520
UPC: 889545037999
Intended for Street Use: Yes
For Use with Stock Calipers: No
Rotor Construction: Vented
Rotor Style: Solid surface
Rotor Outside Diameter (in.): 11.00 in.
Brake Rotor Bolt Pattern (in.): Triple 5 x 4.50 in./5 x 4.75 in./5 x 5.00 in.
Brake Rotor Bolt Pattern (mm): Triple 5 x 114.30mm/5 x 120.65mm/5 x 127.00mm
Nominal Thickness (in.): 0.810
Rotor Material: Iron
Rotor Finish: Natural
Quantity: Sold individually.
Notes: Offset dimension is 1.91 in. Stud diameter is 0.52 in. For internal parking drum brake.
Description:
Wilwood Ultralite HP 32 vane rotor and hats extend the service life of brakes on heavier competition vehicles and other severe-duty applications. These replacement rotors are precision-machined to less than .001 in. tolerance for overall flatness, parallelism, and radial runout on Wilwood's long-grain carbon iron castings. Plus, their superior thermal conductivity and stability properties resist distortion and fatigue. For racing or everyday use, Wilwood Ultralite HP 32 vane rotor and hats are a great choice. Order the size, surface style, and bolt pattern needed for your application.
